Retaining ring 14 DIN7993B
Retaining ring 14 DIN7993B
- Code: 48007181
- In Stock: 106 pcs.
Updated: 05.12.2025 17:52
| Retaining rings dimensions DIN7993B | |
| Outside diameter d1 (mm) | 15,2 |
| Cross section d2 (mm) | 1 |
| Hole diameter d3 (mm) | 14 |
| Groove diameter d4 (mm) | 15 |
| Opening range e (mm) | 6 |
| Minimum groove cros section radius r (mm) | 0,6 |
| Details | |
| Material type | Stal |
| Norm design | DIN7993B |
- Brand: OEM
- SKU: 32496
$0.25/pcs.
5 pcs. or more $0.15/pcs.
10 pcs. or more $0.10/pcs.
25 pcs. or more $0.08/pcs.
50 pcs. or more $0.06/pcs.
100 pcs. or more $0.04/pcs.
250 pcs. or more $0.03/pcs.
500 pcs. or more $0.02/pcs.
1000 pcs. or more $0.02/pcs.
Description
The DIN 7993B snap ring is an essential component in many mechanical structures. Its main task is to secure various elements from falling out or shifting.
Technical parameters:
- Material: High-strength steel
- Standard: DIN 7993B
- Application: Mounting bearings, bushings, sealing rings and other components
- Securing bearings and bushings in holes
- Mounting sealing rings
- Stabilizing components in mechanisms
