Rod seal RSD 30x40x6,5 PU [2ERSD210]

The RSD type gland seal from the Italian manufacturer Artic Seals is a double-lip ring made of C0 polyurethane (based on polyester-caprolactam), designed for use in hydraulic cylinders. Both lips are pressed against the cooperating surface due to the elasticity of the material. An additional lip stabilizes the seal and protects against external contamination. The design prevents the stick-slip effect and supports the operation of the seal at low temperatures.

Technical data:

• Working pressure: up to 400 bar (at 60°C)
• Linear speed: up to 0.5 m/s
• Temperature range: from -35°C to +100°C (temporarily up to 110°C)
• Hardness: 93 Shore A ±2
• Material: C0 polyurethane with high resistance to wear and low permanent deformation

The product with the manufacturer's code [2ERSD210] has dimensions of 30x40x6.5 mm. Made of polyurethane (PU), it provides excellent sealing in various working conditions.
