Seal kit for CS13/CX13 EDBRO -3 stages

Complete, original repair kit designed for 3-stages EDBRO – CS13/CX13 series telescopic hydraulic cylinders. The kit includes all necessary components for a full and professional cylinder overhaul.

Kit contents:

• seals

• wiper seals

• guide rings

• O-rings

• static seal

• bottom cover

• fastening components

Specification by rod diameter:

Rod Ø 98 mm

• Wiper seal EWM98/01 (44487) – 1 pc (98×108×4.5/7)

• Piston seal SAM98/01 (44496 + 47701) – 1 pc (98×108×12.2)

• Guide ring BRH98/04 – 2 pcs

Rod Ø 117 mm

• Wiper seal EWM117/01 – 1 pc (117×127×5.8/8.8)

• Piston seal SAM117/01 (44497 + 47702) – 1 pc (117×127×14)

• Guide ring BRH117/04 – 2 pcs

Rod Ø 136 mm

• Wiper seal EWM136/01 (44489) – 1 pc (136×146×5.8/8.8)

• Piston seal SAM136/03 (44489 + 47703) – 1 pc (136×146×14)

• Guide ring BRH136/04 – 2 pcs

Application:

Suitable for telescopic cylinders of the following series:

• CS13

• CX13
