  • Code: 10043755
  • In Stock: 9 pcs.
Updated: 11.07.2025 11:31
Details
Original YES
$19.75/pcs.

Description

WEICONLOCK AN 305-42 is a single-component sealing adhesive used for protecting pipe and flange connections in hydraulic, pneumatic, and gas systems. It holds DVGW certification for gas applications. The product cures in the absence of air between tightly fitted metal surfaces, prevents loosening caused by vibration or shocks, and offers resistance to chemicals and solvents. The WEICON Pen applicator ensures even and accurate dispensing.

Technical details:

  • Color: brown

  • Fluorescent: yes

  • Thread connections: up to M 20 / R ¾"

  • Viscosity at 25 °C: 500 mPa·s

  • Max gap fill: 0.15 mm

  • Breakaway torque: 12–15 Nm

  • Prevailing torque: 18–22 Nm

  • Strength (DIN 54452): 8–12 N/mm²

  • Fixture time: 10–20 minutes

  • Full cure: 2–4 hours

  • Temperature resistance: -60°C to +150°C

  • ISSA-Code: 75.628.10/11/12

  • IMPA-Code: 812918/19/20

  • Certification: DVGW
