Circlip A(Z)18 DIN471

Updated: 02.01.2025 11:00

Retaining rings dimensions DIN471
The inner diameter of the ring d3 (mm)	16,5
Height foot ring a (mm)	3,9
The ring width b (mm)	2,4
Diameter holes for ring opening d5 (mm)	2
Thickness of the ring s (mm)	1,2
Shaft diameter d1 (mm)	18
Groove diameter d2 (mm)	14
Grove width m (mm)	1,3
Minimum length to the face of the shaft n (mm)	1,5
Details
Material type	Stal
Norm design	DIN471

754.29Ft/pcs.

5 pcs. or more 188.57Ft/pcs.

10 pcs. or more 94.29Ft/pcs.

30 pcs. or more 42.43Ft/pcs.
