High pressure oil seal 17x28x5 BAHDSN NBR

The High-Pressure Shaft Seal 17x28x5 BAHDSN NBR is designed for shaft sealing in hydraulic motors used in hydrokinetic drives.
It features an open metal insert on the front side, providing a stable contact surface and preventing deformation under pressure.
Made of nitrile rubber (NBR), it is resistant to oils and greases.

Dimensions:

• 17 x 28 x 5 mm (d1 x D x b)

• 0.669" x 1.102" x 0.197"

Technical details:

• Manufacturer: SOG (Taiwan)

• Material: NBR (nitrile rubber)

• Max working pressure: 150 bar

• Average working pressure: 100 bar

• Max linear speed: 2 m/s

• Interchangeable with: BAHD, BAHDSN, BAKHDSN

Applications:

• Shaft sealing in hydraulic motors

• Hydrokinetic drive systems
