High pressure oil seal 35x46x4,9 BAKHDSN NBR+PTFE

The high-pressure oil seal 35x46x4.9 BAKHDSN NBR+PTFE is a specialized sealing element used in hydraulic motors and hydrostatic drives.
Made from a combination of nitrile rubber (NBR) and PTFE, this seal provides excellent resistance to pressure and wear.
Its open metal insert on the front side ensures stable contact and prevents deformation under load.
It is designed for use with hydraulic oils and fuels in demanding applications.

Technical data:

• Inside diameter: 35 mm (≈ 1.38 inch)

• Outside diameter: 46 mm (≈ 1.81 inch)

• Height: 4.9 mm (≈ 0.19 inch)

• Material: NBR + PTFE

• Working pressure: up to 150 bar

• Linear speed: up to 2 m/s

Seals marked BAHD, BAHDSN, and BAKHDSN are interchangeable and commonly used in heavy-duty hydraulic systems.
