  • Code: RSD 0060 0100 045 C0
  • In Stock: 6 weeks
Updated: 25.07.2025 12:40
Hydraulic seals dimension
Rod diameter d (mm) 6
Groove Diameter D (mm) 10
Seal width h (mm) 4,5
Details
Seal type RSD
Material type PU
Material code C0
0.00€/pcs.

Description

The RSD type rod seal from the renowned Italian manufacturer Artic Seals is a double-lip ring made of C0 polyurethane (based on polyester-caprolactam). It is a product designed for use in hydraulic cylinders. Thanks to the elasticity of the material, both lips are pressed against the cooperating surface. An additional lip stabilizes the seal and protects against external contamination. The design prevents the stick-slip effect and supports the operation of the seal at low temperatures.

Technical data:

  • Working pressure: up to 400 bar (at 60°C)
  • Linear speed: up to 0.5 m/s
  • Temperature range: from -35°C to +100°C (temporarily up to 110°C)
  • Hardness: 93 Shore A ±2
  • Material: C0 polyurethane with high resistance to wear and low permanent deformation

The product with dimensions 6x10x4.5 PU, marked with the symbol [2ERSD003], is an excellent solution for all those looking for a reliable and durable rod seal.
