Wiper K703 70x82,2x8,1

The K703 wiper is a two-piece, single-acting rod wiper consisting of a specially profiled PTFE ring and an NBR o-ring acting as the energizing element. The PTFE profile features a working edge angled at 20° and 60° that wipes contaminants from the rod surface during retraction while leaving a residual oil film. The NBR o-ring provides the initial pre-load of the PTFE lip against the rod and seals statically against the groove base.

The two-piece design allows operation at high sliding speeds with the low friction characteristic of PTFE-based materials. The K703 wiper is used in mobile hydraulics, aluminium injection machines and industrial equipment where reliable protection against ingress of solid particles and external contaminants is required.

• Seal type: K703 – two-piece single-acting rod wiper
• Material: PTFE PT6003 (profile ring) + NBR NB7001 (o-ring energizer, 70 Shore A)
• Inner diameter d: 70 mm (2.756″)
• Outer diameter D: 82.2 mm (3.236″)
• Height H: 8.1 mm (0.319″)
• Tolerance d: f8 | Tolerance D: H9
• O-ring energizer: 75.79 × 3.53 mm
• Temperature range: –30°C to +105°C (NBR)
• Maximum sliding speed: 5.0 m/s
• Application: mobile hydraulics, aluminium injection machines, industrial equipment
• Brand: OEM
• Product code: 48005494
• SKU: 7018
